Lightbar FX250-SP

XENON OÜ

€139,00 €189,00
SKU: LEDDL103-SP





High-performance LED auxiliary lights are permitted for use and improve visibility on roads

Not only does reliable and brilliant light improve visibility for drivers, above all, it improves safety on the road. The LEDriving Lightbar FX250-SP automotive auxiliary light gives drivers a powerful supplemental high beam that is approved for use on roads.
Even in difficult visibility conditions, the LED auxiliary light provides better perception of oncoming traffic with ten high-performance LEDs and 2700 lumen. Along with improving one’s own safety, it improves road safety overall.
The intelligent reflector design of the LED high beam offers extreme efficiency with even light distribution. The highly concentrated light greatly improves far field illumination. The light beam from the LED automotive headlight reaches up to 360 meters.

Durability & wide range of applications
Daily use demands quite a bit from a vehicle. The stress doesn’t stop at the LED auxiliary light. This is why it is equipped with an extremely robust polycarbonate lens that can withstand even harsh conditions for longer periods.
But high-quality materials aren’t the only factor contributing to its durability: The integrated driver and thermal management system also plays a role in the long lifetime of the LED high beam light.
Over and under voltage protection ensure that the circuit is automatically shut off when power exceeds the predetermined current for a specified amount of time. This temporarily prevents overheating and extends the lifetime of the LED auxiliary light.
More light is important, and not only on roads: Powerful lighting is important off-road, on unlit dirt or forest roads and in agriculture.
This is why the LEDriving Lightbar FX250-SP LED auxiliary light can be easily installed on 4x4 and utility vehicles, and industrial and construction vehicles.

Technical Data

Country specific categorizations

Order reference

LEDDL103-SP

Product information

Application (Category and Product specific)

Additional high beam application

Electrical data

Nominal voltage

12/24 V

Nominal wattage

30 W

Test voltage

13.5 V

Photometrical data

Luminous flux

2700 lm

Color temperature

6000 K

Light distance at 1lx

360 m

Dimensions & weight

Width

94.0 mm

Height

77.0 mm

Length

400.0 mm

Product weight

1200.00 g

Lifespan

Lifespan Tc

5000 h

Additional product data

Connector to lamp

DT Connector

Capabilities

Technology

LED

Certificates & standards

Standards

ECE R10, R112

Approval marks – approval

E4 approval

Type of protection

IP67

Logistical data

Commodity code

851220009000
